產品參數
噴砂房型號 | 工作尺寸 m | **處理工件尺寸 m | 大門尺寸 m | 噴槍數量 |
TB-SF543P | 5X4X3 | 3.4X3X2 | 3.2X2.2 | 1 |
TB-SF643P | 6X4X3 | 4.4X3.8X2 | 3.2X2.2 | 1 |
TB-SF653P | 6X5X3 | 4.4X3.8X2 | 4.2X2.2 | 1 |
詳細介紹:
騰博機械噴砂房主要型號及技術參數
噴砂房型號 | 工作尺寸 m | **處理工件尺寸 m | 大門尺寸 m | 噴槍數量 |
TB-SF543P | 5X4X3 | 3.4X3X2 | 3.2X2.2 | 1 |
TB-SF643P | 6X4X3 | 4.4X3.8X2 | 3.2X2.2 | 1 |
TB-SF653P | 6X5X3 | 4.4X3.8X2 | 4.2X2.2 | 1 |
TB-SF654P | 6X5X4 | 4.4X3.8X3 | 4.2X3.2 | 1 |
TB-SF853P | 8X5X3 | 6.4X3.8X2 | 4.2X2.2 | 2 |
TB-SF854P | 8X5X4 | 6.4X3.8X3 | 4.2X3.2 | 2 |
TB-SF773P | 7X7X3 | 5.4X5.4X2 | 6.0X2.2 | 2 |
TB-SF774P | 7X7X4 | 5.4X5.4X3 | 6.0X3.2 | 2 |
TB-SF1054P | 10X5X4 | 8.4X3.8X2 | 4.2X3.2 | 2 |
TB-SF1064P | 10X6X4 | 8.4X4.8X3 | 5.2X3.2 | 2 |
TB-SF1254P | 12X5X4 | 10.4X3.8X3 | 4.2X3.2 | 2 |
TB-SF1265P | 12X6X5 | 10.4X4.8X4 | 5.2X4.2 | 2 |
TB-SF1354P | 13X5X4 | 11.4X3.8X3 | 4.2X3.2 | 2 |
TB-SF1364P | 13X6X4 | 11.4X4.8X4 | 5.2X3.2 | 2 |
TB-SF1554P | 15X5X4 | 13.4X3.8X3 | 4.2X3.2 | 2 |
TB-SF1555P | 15X5X5 | 13.4X3.8X4 | 4.2X4.2 | 2 |
